Chatillon DG-100KG机械测力计的详细资料

Chatillon DG-100KG机械测力计

DG 系列是一套出色而经济的解决方案，于拉伸或压缩测试，其测试上限为 500 磅力(2.5 千牛)。该机械测力计具有 2.25 英寸刻度盘，可作为手持装置，或装配...

DG Series Mechanical Force Gauge

The CHATILLON® DG Series mechanical force gauge is ideal for a wide range of force testing applications up to 500 lbf (2.5kN). Based on our popular DPPH Series force gauge， the DG Series features a larger， 2.25-inch dial for improved resolution and readability， peak hold button， durable plastic housing， universal mounting plate， ergonomic shape and improved accuracy of +0.5% of full scale. The DG gauge is an excellent， economical solution for tensile or compression testing.Chatillon DG-100KG机械测力计
The DG Series may be used as a hand-held device or equipped with an optional handle set for two-hand operation. It is ideal for test stand applications，and when combined with the MT500 Series mechanical test stand， offers you a versatile， economic test system with a capacity of up to 500 lbf (2.5kN).

The DG Series features an an easy to read concentric dial that measures clockwise only. Dial rotates 360-degrees for taring. A peak hold switch captures peak readings and can be easily and quickly returned to zero. A mechanical overload feature protects the gauge from damage. Available in lbf， kgf or N units of measure. DG Series gauges come complete with protective carrying case and a set of stainless steel attachments. A Certificate of Calibration with NIST Data is supplied standard.

Features Chatillon DG-100KG机械测力计
n Three Graduation Styles
 - LBF
 - KGF
 - Newtons
n Tensile (Pull) and Compression (Push) Testing
n Peak Load Switch
n Tare Ring
n Intrinsically Safe
n NIST Calibration with Data
n 2 Year Warranty  Chatillon DG-200机械测力计

Specifications
Accuracy： +0.5% of Full Scale
Overload Capacity： 110% of Rated Capacity
Maximum Overload： 150% of Rated Capacity
Tare Capacity： 10% of Rated Capacity
Dial Resolution： 0.5% of Full Scale
Deflection (Full Scale)： 10mm (.394 inches)
Operating Temperature： 40°F to 110°F
 5°C to 45°C
Instrument Weight： 4.7 lbs (0.68 kg)
Shipping Weight： 8.4 lbs (3.80 kg)

该产品由深圳市硬汉视频免费完整版在线下载电子科技有限公司提供，销售商地址位于深圳市南山区前海路振业国际商务中心1206。请您仔细阅读产品使用说明书，正确使用。

如果想试用该产品，请以下单位：

硬汉视频免费完整版在线下载电子主要销售通信设备、仪器仪表、电力设备、热工仪表、校准设备及工具配件。
